Description
Part No : VCG409024TFXPB1
The NVIDIA® GeForce RTX® 4090 is the ultimate GeForce GPU. It brings an enormous leap in performance, efficiency, and AI-powered graphics. Experience ultra-high performance gaming, incredibly detailed virtual worlds, unprecedented productivity, and new ways to create. It’s powered by the NVIDIA Ada Lovelace architecture and comes with 24 GB of G6X memory to deliver the ultimate experience for gamers and creators.
Ada Lovelace architecture
Ahead of its time, ahead of the game.
Powered by
the NVIDIA Ada Lovelace architecture
Double Ball Bearing Fan
Adopts with 3 100mm double ball bearing round fans. Compare to traditional 90mm fans, offer 40% more airflow and gain 55% air pressure. In addition the round fan blade converge the airs to enhance thermal performance.
Thermal Module
Fans
3x 100mm double ball bearing offers 70,000+hours lifespan
Giant Heatsink
Dense fins greatly increase the heat dissipation area
8x Heatpipes
Adopts 2x Φ=8mm + 6x Φ=6mm heatpipes to conduct heat to the fin
Vapor Chamber
Direct contact with GPU to efficiently transfer heat
NVIDIA CUDA Cores 16384 |
Clock Speed 2235 MHz |
Boost Speed 2520 MHz |
Memory Speed (Gbps) 21 Gbps |
Memory Size 24GB |
Memory Interface 384-bit |
Memory Bandwidth(GB/sec) 1008 Gbps |
TDP 450W |
NVLink Not Supported |
Outputs 3x DisplayPort 1.4, HDMI 2.1 |
Multi-Screen Up to 4 |
Resolution 7680 x 4320 at 120Hz (Digital) |
Power Input One 16-Pin (One 16-pin to Four 8-pin) |
Bus Type PCI-Express 4.0 x16 |
Note Accessories: PCIe5 12VHPWR Adapter and VGA Support Kits |
Item Dimension (L"xW"xH") 16 x 8 x 5 Weight 5 lbs Warranty Information 3 years |
