Kingston ME KSM32ED8 16HD 16GB 3200MHz DDR4 ECC CL22 DIMM 2Rx8 Hynix D Retail

Kingston's KSM32ED8/16HD is a 2G x 72-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 2Rx8, ECC, memory module, based on eighteen 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:

FEATURES

• Power Supply: VDD = 1.2V Typical

• VDDQ = 1.2V Typical

• VPP = 2.5V Typical

• VDDSPD = 2.2V to 3.6V

• Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals

• Low-power auto self refresh (LPASR)

• Data bus inversion (DBI) for data bus

• On-die VREFDQ generation and calibration

• Dual-rank

• On-board I2 serial presence-detect (SPD) EEPROM

• Temperature sensor with integrated SPD

• 16 internal banks; 4 groups of 4 banks each

• Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)

• Selectable BC4 or BL8 on-the-fly (OTF)

• Fly-by topology

• Terminated control command and address bus

• PCB: Height 1.23” (31.25mm)

• RoHS Compliant and Halogen-Free

CL(IDD)
22 cycles

Row Cycle Time (tRCmin)
45.75ns(min.)

Refresh to Active/Refresh Command Time (tRFCmin)
350ns(min.)

Row Active Time (tRASmin)
32ns(min.)

Maximum Operating Power
https://www.kingston.com/dataSheets/KSM32ED8_16HD.pdf

UL Rating
94 V - 0

Operating Temperature
0 ^o C to +85 ^o C

Storage Temperature
-55 ^o C to +100 ^o C

Item Dimension (L inchxW inchxH inch)
7 x 3 x 1

Weight
1.00 lb

Warranty Information
Lifetime Warranty
