Fractal Design CS FD-C-DEF7C-02 Define 7 Compact MT Dark Tinted TG Window ATX

The new Define 7 Compact takes the strongest features of the contemporary 7 Series design and places them in a conveniently compact frame. Highly modular for its size, the Define 7 Compact is easily customizable to meet your exact needs – and the instantly removable top panel ensures an easy build, even with high-end components.

Features


Compact yet spacious interior accommodates ATX, mATX and mITX motherboards

Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm

Support for two 2.5”/3.5” drives (plus two more via optional multi-bracket), and up to four 2.5” drives (two 2.5” brackets included)

Top panel effortlessly swaps from solid steel to filtered ventilation

New removable top panel design opens up to fully expose the case interior for effortless installation and cable routing

Silence-optimized construction with industrial sound-damped front, top, and side panels

Brushed aluminum front and top-latching side panels offer a clean sophisticated look

Install up to 7 x 120 mm or 4 x 140 mm fans (1 x 120 mm and 1 x 140 mm Dynamic X2 fans included)

Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps

Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup

Ventilated PSU shroud with two-part removable cover for optimal coverage and front radiator support

Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access

Integrated cable guides with Velcro straps further simplify cable management behind the board

Front radiator support: 120/140/240/280/360 mm (145 mm max width)

Top radiator support: 120/240 mm (max 40 mm motherboard component height)

Rear radiator support: 120 mm

Bottom radiator support: 120 mm (requires removal of HDD cage)

Series
Define 7 Compact

Type
ATX Mid Tower

Color
Black

Case Material
Steel

With Power Supply
No

Power Supply Mounted
Bottom

Power Supply
ATX

Motherboard Support
ATX / MicroATX / Mini-ITX

Side Panel Window
Yes

LED
No

Removable Filter
Top panel
2 x Front
Bottom, full length

External 5.25" Drive Bays
0

Internal 3.5" Drive Bays
2 included, 4 max via optional multibrackets

Internal 2.5" Drive Bays
2 trays included, 4 positions total

Expansion Slots
7

Front Ports
1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button

Fan Options
Total fan mounts: 7 x 120 or 4 x 140 mm and 2 x 120 mm
Front: 3 x 120 or 2 x 140 mm, (1 x Dynamic X2 GP-14 included)
Top: 2 x 120 or 2 x 140 mm
Rear: 1 x 120 mm, (1 x Dynamic X2 GP-12 included)
Bottom: 1 x 120 mm (requires removal of HDD cage)

Radiator Options
Front: Up to 360/280 mm (max 145 mm width)
Top: Up to 240 mm
Rear: 120 mm
Bottom: 120 mm (requires removal of HDD cage)

Item Dimension (L"x W"x H")
22 x 13 x 21
Weight
44.00 LB
Warranty Information
2 YEARS
