ASRock Video Card RX7900XTX PG 24GO AMD Radeon RX 7900 XTX Phantom Gaming 24GB OC GDDR6 Retail

AMD Radeon™ RX 7900 XTX

Phantom Gaming 24GB OC

RX7900XTX PG 24GO

PRODUCT BRIEF:

Clock: GPU / Memory

Boost Clock*: Up to 2615MHz / 20Gbps

Game Clock**: 2455MHz / 20Gbps

Key Specifications

AMD Radeon™ RX 7900 XTX GPU

24GB GDDR6 on 384-Bit Memory Bus

96 AMD RDNA™ 3 Compute Units (With Rt+Ai Accelerators)

96MB AMD Infinity Cache™ Technology

PCI® Express 4.0 Support

3 x 8-pin Power Connectors

3 x DisplayPort™ 2.1 / 1 x HDMI™ 2.1

Key Features

Polychrome SYNC

Phantom Gaming 3X Cooling System

Striped Ring Fan

Reinforced Metal Frame

Stylish Metal Backplate

0dB Silent Cooling

Super Alloy Graphics Card

*Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.

Graphics Engine
- AMD Radeon RX 7900 XTX

Bus Standard
- PCI Express4.0 x16

DirectX
- 12 Ultimate

OpenGL
- 4.6

Memory
- GDDR6 24GB

Engine Clock
- Boost Clock: Up to 2615 MHz
- Game Clock: 2455 MHz
Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

Stream Processors
- 6144

Memory Clock
- 20 Gbps

Memory Interface
- 384-bit

Resolution
- Digital Max Resolution: 7680 x 4320

Interface
- 3 x DisplayPort 2.1
- 1 x HDMI 2.1
DisplayPort (DP) 2.1 on any one or two ports. DisplayPort (DP) 1.4a on any and up to 4 ports simultaneously.

HDCP
- Yes

Multi-view
- 4

Recommended PSU
- 1000W

Power Connector
- 3 x 8-pin

Accessories
- 1 x Quick Installation Guide

Item Dimension (L"xW"xH")
16 x 9 x 4

Weight
6.61 lbs

Warranty Information
NA
