Description
Connect To the PoE Network Video Recorder (NVR) for Small Networking
For such small monitoring scenarios as small shops and restaurants.Monitoring requirements can be met by simply connecting the camera to the PoE NVR.
Connect To the PoE Switch for Medium and Large Networking
For such medium and large monitoring scenarios as markets, industrial zones and car parks, you can connect the camera to the PoE switch for networking.
Clear monitoring details from 4MP UHD images
Equipped with a high-performance CMOS image sensor, the camera can display 4MP UHD images (2560*1440) with more monitoring details.
Super photosensitive ability, better performance in low light
Using a high-sensitivity sensor, the camera is more light-sensitive than common cameras and can display finer images than common infrared cameras.
Audio Pickup Over 5 m, Sync Audio and Video
With an inbuilt highly sensitive microphone which supports remote audio pickup over 5 m, the camera can sync audio and video.
Compatible With NVRs of Other Brands With ONVIF Supported
It can be used with mainstream NVRs in the market, featuring high compatibility.
Hardware Specifications
Ports
Power: DC 12V 1A
Ethernet: 1 x RJ45 100M
Ethernet port on tail line
Lens
4mm at F2.2/2.8mm at F2.2
Video Specifications
Resolution
2560 x 1440
Coding Standard
H.265/H.264
Day and Night Shift Mode
Built-in IR-CUT double filter
Noise Reduction
3D digital noise reduction
DWDR
Support
Backlight Compensation
Support
ROI
Support
Others
Smart Alarm
S-motion detection and Human Shape detection and Customized area detection
Infrared Night Vision Distance
30 Meters
Temperature
Operating temperature: -10oC to 50oC
Storage temperature: -40oC to 70oC
Humidity
Operating humidity: 10%-95%RH (non-condensing)
Storage humidity: 3% to 95%RH (non-condensing)
Certification
CE
RoHs
FCC
Waterproof level
-
Audio
Built-in microphone
Network protocol
RTSP
HTTP
DHCP
DDNS
ONVIF
Internet Network protocol
IPV4
Add device method
Wired
Package Contents
Security camera, Wall-mounted accessory kit, Quick installation guide, General Public license notice
