Description
Cost-efficient 8-core 2.5GbE NAS, supporting M.2 SATA/NVMe SSD caching, PCIe expansion, and 4K HDMI display
(Supports QTS or QuTS hero operating system)
Powered by the x86 architecture Zhaoxin KaiXian KX-U6580 8-core processor, the TVS-675 provides businesses with a modern 2.5GbE NAS solution to tackle everyday tasks like file backup/restore, and to boost team collaboration with higher productivity. Besides hardware advantages with built-in M.2 SSD slots for cache acceleration and PCIe expansion, the TVS-675 supports abundant business and media applications (including snapshot protection, virtual machines, cloud storage gateways, 4K HDMI display, and real-time transcoding) alongside expandable storage capacity and install-on-demand apps, making it a cost-effective and reliable data storage and media NAS.
1
Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports.
2
Install high-performance M.2 PCIe NVMe Gen 3 x1 SSDs or economical SATA 6Gb/s SSDs in the dedicated SSD slots for caching with improved random I/O or high-performance storage pools.
3
Two PCIe Gen 3 slots allow for installing 2.5/5/10GbE adapters, QM2 cards, or QXP storage expansion cards.
4
4K media playback and real-time transcoding directly output videos to an HDMI 2.0 display (up to 4K at 60Hz).
5
Supports storage for virtualization hosts multiple virtual machines and containers to run a wide range of applications on one NAS device.
6
Flexibly scale the total storage capacity to match business growth by connecting QNAP expansion enclosures.
CPU
ZhaoXin KX-U6580 8-core 2.5GHz processor
CPU Architecture
64-bit x86
Graphic Processors
ZhaoXin C-960 Graphics
Floating Point Unit
Yes
Encryption Engine
Yes (AES-NI)
Hardware-accelerated Transcoding
Yes
System Memory
8 GB SODIMM DDR4 (1 x 8 GB)
Maximum Memory
64GB (2 x 32 GB)
Memory Slot
2 x SO-DIMM DDR4
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
6 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
Yes
M.2 Slot
2 x M.2 2280 PCIe Gen 3 x1 or SATA 6Gb/s slots
SSD Cache Acceleration Support
Yes
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2
5 Gigabit Ethernet Port (5G/2.5G/1G/100M)
Optional via an adapter
10 Gigabit Ethernet Port
Optional via an adapter
Wake on LAN (WOL)
Yes
Jumbo Frame
Yes
