Adesso SC NuScan 2600U 2D Handheld Barcode Scanner (USB) Retail

The Adesso NuScan 2600U is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 2600U is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. The NuScan 2600U can be cleaned periodically. With all these great features, the NuScan 2600U is truly your ultimate barcode scanner.

Features:

2D Scanning Engine

The 2D scanning engine offers decoding capability for 2D barcodes like PDF417, Data Matrix, QR Code, MicroQR as well as common 1D barcodes.

Reliable Data Collection

It’s built-in decoder can read the majority of 1D & 2D barcodes and it’s driver-less operation makes it easy to use with both Windows® and Mac® operating systems.

Superior Scanning Performance

Equipped with its CMOS sensor the device has a motion tolerance of 5 inches per second, offering fast and accurate scanning results.

Drop Protection

With its drop protection design, the NuScan 2600U less likely to become damaged due to accidental drops.

Long Scanning Range

The 2D CMOS decoding engine is able to scan barcodes up to 12 inches scan depth.

Mechanical:
Cable Length:
6 Ft (1.8meters)

Electrical:
Power Input voltage:
5 +/- 5% VDC
Working Current:
120mA
Light Source:
White LED and 640nm visible Red LED

Performance:
Interface:
USB
Sensor:
640x480 CMOS Sensor
Minimum Resolution Supported (2D):
5 mil
Depth of Field:
0-10 inches ( at 13mil UPC-A, PC 100%)
Scan Rate:
30 frames per second
Scan Angle
Roll: +/-30^o, Pitch: +/-60^o, Skew: +/-60^o
Print Contrast:
>25%
Alert Operation:
Blue LED indicator and beeper

Environmental
Operating Temperature:
-20^oC to 50^oC (-4^oF to 122^oF)
Storage Temperature:
-40^oC to 70^oC (-40^oF to 158^oF)
Operating Humidity :
20% - 95% (non-condensing)
Storage Humidity :
5% to 95% (non-condensing)
Shock Resistance:
Withstanding 1.5m freefall drops
Regulatory
FCC, CE RoHS

Supported Symbologies
1D: EAN-8, EAN-13, EAN-13 2 add-on, EAN-13 5add-on, ISSN, ISBN, UPC-A, UPC-E, Code 11, Code 32 Code 39, Code 93, Code 128, Codabar, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5
2D: PDF417, MicroPDF417, MicroQR, Data Matrix, QR, Aztec

System Requirements:
Windows2000 / XP / Vista / 7 / 8 / 10
Mac OS X
Interface: USB

Includes:
Adesso NuScan 2600U Handheld 2D Barcode Scanner
Quick Start Guide

Item Dimension (L"x W"x H")
11 x 8 x 2
Weight
4.00 LB
